- ISO 15552-compliant profile cylinder (Ø 32–125 mm; stroke up to 2 800 mm)
- Self-adjusting pneumatic cushioning (PPS) at both ends – adapts to load/speed
- Low-friction piston design, ideal for high-speed or slow, uniform movements
- Rotation protection options (Q): anti-rotate piston rod
- Optional clamping unit & end-position lock (E1/E2/E3)
- Wide environment variants: Corrosion protection (R3), heat-resistant seals (up to +150 °C), ATEX-certified versions
| Parameter | Value |
|---|---|
| Brand | Festo |
| Bore Diameter (Ø) | 32 – 125 mm |
| Stroke Length | Up to 2,800 mm |
| Operating Pressure | 0.06 – 1.2 MPa (max 1.5 MPa) |
| Cushioning | Pneumatic self-adjusting (PPS) at both ends |
| Friction Characteristics | L / U / L1 variants for low friction |
| Rotation Protection (Q) | Optional |
| Clamping Unit | Optional |
| End-Position Lock (E1/E2/E3) | Optional |
| Sealing & Variants | R3 corrosion, T1–T4 temperature, ATEX-compliant |
| Mounting Position | Any orientation |
| Sensor Slots | ISO 15552 profiled with integrated slots |
| Piston Ø Examples | 32, 40, 50, 63, 80, 100, 125 mm |
The Festo DSBC is a robust ISO 15552-compliant pneumatic profile cylinder designed for diverse automation tasks. Key benefits include:
-
Adaptable vibration damping with self-adjusting PPS cushions on both ends, optimizing performance across varying loads and speeds.
-
Low dynamic friction options (L, U, L1, PPS, etc.) ensure fast or precise, slow piston movements.
-
Optional rotation prevention, clamping, and positive end-position locking enhance safety and accuracy.
-
Multiple environmental variants support harsh conditions: R3 high corrosion resistance, high-temperature seals (T1–T4), and ATEX-compliant versions.
-
Profiled body with sensor slots, enabling clean, modular integration with proximity sensors.
The DSBC series is ideal for precise, high-performance pneumatic applications—locking systems, assembly machines, and motion control—requiring robust cushioning, low wear, and flexible adaptation.
